D-1653N Intel Xeon D 8-Core 2.80GHz 12MB Cache Socket FCBGA1667 Processor
Mfg Part No:
Global Part Number(GPN):
D-1653N
Global Part Number(GPN):
1492282746
Looking for a large quantity of D-1653N? Call us at +1 (888) 898-8012 or Request a Quote below and one of our sales representative will get in touch with you very soon.
Request for Quote
Please call at +1 (888) 898-8012 and one of our representative will be happy to assist you with part no D-1653N. Or Request a Quote below:
Technical Specifications
| Processor - Package Model: D-1653N Socket Type: BGA1667 | |
| Brand | Intel |
| Part No. | D-1653N |
| Processor Type | Server |
| Series | Xeon D Processor |
| Core Model Type/ProcNo. | D-1653N |
| Processor Code Name | Hewitt Lake |
| Manufacturing Technology | 14 nm |
| # of Cores | 8 |
| # of Threads | 16 |
| Clock Speed | 2.80 GHz |
| Max Turbo Frequency | 3.20 GHz |
| L3 Cache Size | 12 MB |
| Thermal Power | 65 Watts |
| Max Memory Size | 128 GB |
| Memory Types | DDR4-2400 |
| Maximum Memory Speed | 2400 MHz |
| Memory Channels | 2 |
| ECC Memory Supported | Yes |
| CPU Socket Type | BGA1667 |
| TJUNCTION | 105 °C |
| Package Size | 37.5mm x 37.5mm |
| TCASE | 71 °C |
| Embedded Options Available | No |
| Scalability | 1S |
| PCI Express | 2.0 |
| PCI Express Configurations |
x16 x4 x8 |
| Max # of PCI Express Lanes | 32 |
| # of USB Ports | 8 |
| USB Revision | 2.0 |
| Total # of SATA Ports | 6 |
| Integrated LAN | 4x 10GbE |
| Max # of SATA 6.0 Gb/s Ports | 6 |
| Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) |
| Instruction Set Extensions | Intel AVX2 |
| Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel OS Guard Intel Trusted Execution Technology Secure Key |
| Product Condition | OEM |
| Standard Warranty | 21 days |
General Information
OEM CPUs.
D-1653N Intel Xeon D 8-Core 2.80GHz 12MB Cache Socket FCBGA1667 Processor Refurbished
- The CPU you are ordering, if it is designated as OEM it can be NEW or Refurbished.
- Depending on how old the CPU is and how long it has been out of production, the CPU condition may be new, pull, pre-owned, or like-new condition. The older the cpu is the more likely it is out of production. In that case these pre-owned, pulls are the only ones available.
- ALL OEM Cpus are tested before shipping and carry a 21 day warranty for replacement only. There are NO cancellations or returns accepted for these parts.
- Please check your system requirements carefully before ordering CPU's.
- If you are going to use the CPU in a dual-cpu SERVER application or machine then YOU MUST match the SL code for the new CPU with your existing CPU . Please call us if you need help.
- SL codes - All INTEL cpu's are also designated by a Step code or SLcode. This is a 5 digit alpha-numberic code on the cpu itself. Your particular cpu may have many SL codes (think of them as versions of cpus made). In order to run dual cpus in one machine the SL codes must match
- If you have a brand name computer (eg HP, DELL, IBM you must provide us with a HeatSink part number or we will ship you a generic heatsink if you order one from us.)
