CL8068404149204 Intel Core i3-8145UE Dual-Core 2.20GHz 4MB L3 Cache Socket FCBGA1528 Processor
Mfg Part No:
Global Part Number(GPN):
CL8068404149204
Global Part Number(GPN):
1492434237
Looking for a large quantity of CL8068404149204? Call us at +1 (888) 898-8012 or Request a Quote below and one of our sales representative will get in touch with you very soon.
Request for Quote
Please call at +1 (888) 898-8012 and one of our representative will be happy to assist you with part no CL8068404149204. Or Request a Quote below:
Technical Specifications
| Processor - Package Model: i3-8145UE Socket Type: FCBGA1528 | |
| Processor Type | Embedded |
| Processor Family | 8th Generation Intel Core i3 Processors |
| Core Model Type/ProcNo. | i3-8145UE |
| Processor Code Name | Whiskey Lake |
| Manufacturing Technology | 14 nm |
| # of Cores | 2 |
| # of Threads | 4 |
| Clock Speed | 2.20 GHz |
| L3 Cache Size | 4 MB |
| Thermal Power | 15 Watts |
| Memory Types |
DDR4-2400 LPDDR3-2133 |
| Memory Channels | 2 |
| Maximum Memory Bandwidth | 37.5 GB/s |
| CPU Socket Type | FCBGA1528 |
| Max CPU Configuration | 1 |
| TJUNCTION | 100 |
| Processing Die Size | 107 mm2 |
| Processor Graphics | Intel UHD Graphics 620 |
| Graphics Base Frequency | 350 |
| Graphics Max Dynamic Frequency | 1.00 GHz |
| Graphics Output | HDMI/eDP/DP |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | 4096 x 2160 @ 24Hz |
| Max Resolution (DP) | 4096 x 2304 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 60Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.5 |
| Intel Quick Sync Video | Yes |
| # of Displays Supported | 3 |
| Embedded Options Available | No |
| PCI Express | 3.0 |
| PCI Express Configurations | 1 x4 |
| Max # of PCI Express Lanes | 16 |
| Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Hyper-Threading Technology Intel Optane Memory Supported Intel Turbo Boost Max Technology 3.0 Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) Thermal Monitoring Technologies |
| Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Boot Guard Intel OS Guard Intel Software Guard Extensions (Intel SGX) |
| Product Condition | OEM |
| Standard Warranty | 21 days |
General Information
OEM CPUs.
CL8068404149204 Intel Core i3-8145UE Dual-Core 2.20GHz 4MB L3 Cache Socket FCBGA1528 Processor Refurbished
- The CPU you are ordering, if it is designated as OEM it can be NEW or Refurbished.
- Depending on how old the CPU is and how long it has been out of production, the CPU condition may be new, pull, pre-owned, or like-new condition. The older the cpu is the more likely it is out of production. In that case these pre-owned, pulls are the only ones available.
- ALL OEM Cpus are tested before shipping and carry a 21 day warranty for replacement only. There are NO cancellations or returns accepted for these parts.
- Please check your system requirements carefully before ordering CPU's.
- If you are going to use the CPU in a dual-cpu SERVER application or machine then YOU MUST match the SL code for the new CPU with your existing CPU . Please call us if you need help.
- SL codes - All INTEL cpu's are also designated by a Step code or SLcode. This is a 5 digit alpha-numberic code on the cpu itself. Your particular cpu may have many SL codes (think of them as versions of cpus made). In order to run dual cpus in one machine the SL codes must match
- If you have a brand name computer (eg HP, DELL, IBM you must provide us with a HeatSink part number or we will ship you a generic heatsink if you order one from us.)
