FH8068404166107 Intel Core i7-8557U Quad-Core 1.70GHz 8MB L3 Cache 4.00GT/s OPI Socket FCBGA1528 Processor
Mfg Part No:
Global Part Number(GPN):
FH8068404166107
Global Part Number(GPN):
1492432923
Looking for a large quantity of FH8068404166107? Call us at +1 (888) 898-8012 or Request a Quote below and one of our sales representative will get in touch with you very soon.
Request for Quote
Please call at +1 (888) 898-8012 and one of our representative will be happy to assist you with part no FH8068404166107. Or Request a Quote below:
Technical Specifications
| Processor - Package Model: i7-8557U Socket Type: FCBGA1528 | |
| Processor Type | Mobile |
| Series | Core i7 Mobile Processor |
| Core Model Type/ProcNo. | i7-8557U |
| Processor Code Name | Coffee Lake |
| Manufacturing Technology | 14 nm |
| # of Cores | 4 |
| # of Threads | 8 |
| Clock Speed | 1.70 GHz |
| L3 Cache Size | 8 MB |
| Front Side Bus / QuickPath Interconnect | 4.00 GT/s OPI |
| Thermal Power | 15 Watts |
| Max Memory Size | 32 GB |
| Memory Types |
DDR4-2400 LPDDR3-2133 |
| Memory Channels | 2 |
| Maximum Memory Bandwidth | 37.5 GB/s |
| ECC Memory Supported | No |
| CPU Socket Type | FCBGA1528 |
| Max CPU Configuration | 1 |
| TJUNCTION | 100 °C |
| Package Size | 46x24 |
| Processor Graphics | Intel Iris Plus Graphics 645 |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.15 GHz |
| Graphics Video Max Memory | 32 GB |
| Graphics Output | eDP/DP/HDMI/DVI |
| 4K Support | Yes, at 60Hz |
| Max Resolution (DP) | 4096 x 2304 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 60Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel InTru 3D Technology | Yes |
| Intel Clear Video HD Technology | Yes |
| Intel Clear Video Technology | Yes |
| # of Displays Supported | 3 |
| Device ID | 0x3EA6 |
| Embedded Options Available | No |
| PCI Express | 3.0 |
| PCI Express Configurations | 1 x4 |
| Max # of PCI Express Lanes | 16 |
| Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Flex Memory Access Intel Hyper-Threading Technology Intel Identity Protection Technology Intel My WiFi Technology Intel Optane Memory Supported Intel Speed Shift Technology Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) Thermal Monitoring Technologies |
| Instruction Set Extensions | Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
| Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Memory Protection Extensions (Intel MPX) Intel OS Guard Intel Software Guard Extensions (Intel SGX) Secure Key |
| Product Condition | OEM |
| Standard Warranty | 21 days |
General Information
OEM CPUs.
FH8068404166107 Intel Core i7-8557U Quad-Core 1.70GHz 8MB L3 Cache 4.00GT/s OPI Socket FCBGA1528 Processor Refurbished
- The CPU you are ordering, if it is designated as OEM it can be NEW or Refurbished.
- Depending on how old the CPU is and how long it has been out of production, the CPU condition may be new, pull, pre-owned, or like-new condition. The older the cpu is the more likely it is out of production. In that case these pre-owned, pulls are the only ones available.
- ALL OEM Cpus are tested before shipping and carry a 21 day warranty for replacement only. There are NO cancellations or returns accepted for these parts.
- Please check your system requirements carefully before ordering CPU's.
- If you are going to use the CPU in a dual-cpu SERVER application or machine then YOU MUST match the SL code for the new CPU with your existing CPU . Please call us if you need help.
- SL codes - All INTEL cpu's are also designated by a Step code or SLcode. This is a 5 digit alpha-numberic code on the cpu itself. Your particular cpu may have many SL codes (think of them as versions of cpus made). In order to run dual cpus in one machine the SL codes must match
- If you have a brand name computer (eg HP, DELL, IBM you must provide us with a HeatSink part number or we will ship you a generic heatsink if you order one from us.)
