Processor - Package Model: i3-8109U Socket Type: FCBGA1528 | |
Brand | Intel |
Part No. | i3-8109U |
Processor Type | Mobile |
Core Model Type/ProcNo. | i3-8109U |
Processor Code Name | Coffee Lake |
Manufacturing Technology | 14 nm |
# of Cores | 2 |
# of Threads | 4 |
Clock Speed | 3.00 GHz |
L3 Cache Size | 4 MB |
Front Side Bus / QuickPath Interconnect | 4.00 GT/s |
Thermal Power | 20 Watts |
Max Memory Size | 32 GB |
Memory Types |
DDR4-2400 LPDDR3-2133 |
Memory Channels | 2 |
Maximum Memory Bandwidth | 37.5 GB/s |
ECC Memory Supported | No |
CPU Socket Type | FCBGA1528 |
Max CPU Configuration | 1 |
TJUNCTION | 100 °C |
Package Size | 46x24 |
Processor Graphics | Intel Iris Plus Graphics 655 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.05 GHz |
Graphics Video Max Memory | 32 GB |
Graphics Output | eDP/DP/HDMI/DVI |
4K Support | Yes, at 60Hz |
Max Resolution (DP) | 4096 x 2304 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 60Hz |
DirectX Support | 12 |
OpenGL Support | 4.5 |
Intel Quick Sync Video | Yes |
Intel InTru 3D Technology | Yes |
Intel Clear Video HD Technology | Yes |
Intel Clear Video Technology | Yes |
# of Displays Supported | 3 |
Device ID | 0x3EA5 |
Embedded Options Available | No |
PCI Express | 3.0 |
PCI Express Configurations |
1 x2 1 x4 |
Max # of PCI Express Lanes | 16 |
Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Flex Memory Access Intel Hyper-Threading Technology Intel Identity Protection Technology Intel My WiFi Technology Intel Optane Memory Supported Intel Speed Shift Technology Intel Stable Image Platform Program (SIPP) Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) Thermal Monitoring Technologies |
Instruction Set Extensions | Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Memory Protection Extensions (Intel MPX) Intel OS Guard Intel Software Guard Extensions (Intel SGX) Secure Key |
Product Condition | OEM |
Standard Warranty | 21 days |
